MIC-L500 ultrasonic flaw detector
Main Function
Probe automatic calibration
Automatically form DAC, AVG curve by using standard test block
Display the echo parameters (depth D, level P, the distance S, the amplitude H);
16 independent detecting channels,can enter and store any industrial standards;
Storage: 980 pieces of A-scan images;
Four kinds (I, V, U, X type) of weld viewing function, easy judgment of reflecting position;
Automatically calculate the φ value equivalent defects;
High sampling rate, low noise;
Two probes: single crystal probe, double-crystal probe;
USB interface, PC software is convenient for data exchange, statistical analysis and printing.
Features
New design, simple button and easy operation;
Rechargeable Li-ion Battery, continuous working more than 15 hours;
High quality case and shell: water, dust, and oil proof, good anti-jamming capability;
Big bright LCD screen, convenient for detecting in dark or under the sunlight
Technical Parameters
Model | MIC-L500 |
Scanning Range(mm) | 0~1000 |
Vertical linearity error | ≦4% |
Horizontal linearity error | ≦0.1% |
Detecting sensitivity | ≧60dB(depth 200mm,φ2hole) |
Dynamic Range | ≧32dB |
Frequency Range | 0.5~20 MHz |
Gain Range(dB) | 0~110 |
Velocity Range(m/s) | 1000~9999 |
Echo suppression | 0~80% |
Temperature(℃) | 27~70 |
Dimensions(mm) | 240*160*40 |
Weight | 1.3 |
