Specifications
| Optical
system |
Infinity color corrected optical system |
| Viewing head | Trinocular(binocular), 45°inclined, 360°rotatable trinocular head
Interpupillary distance adjustable between:50-75mm, (beam splitting ratio can be 100:0 or 80:20) |
| Eyepiece | High eyepoint wide field plan eyepiece PL10X/22mm, diopter adjustable |
| High eyepoint wide field eyepiece WF15X/13 | |
| High eyepoint wide field eyepiece WF20X/10mm | |
| Metallurgical
objective |
LWD bright field&dark field&DIC plan achromatic metallurgical
objective 5X,10X,20X,50X、100X |
| Nosepiece | Reversed quintuple nosepiece with DIC slot |
| Focusing
adjustment |
Low position coaxial coarse and fine adjustment. with tightness
adjustment. Coarse adjustment range 38 mm; precision of fine adjustment:2um, |
| stage | Three-layer mechanical stage, area 240Wx250L mm,
moving range 50x50mm; Metal stage plate,center hole dia.φ12mm |
| Illumination
system |
Reflection Koehler illumination with iris diaphragm and centerable field
diaphragm , wide-range voltage 90-240V ,12V/100W halogen bulb (single 3W LED option), with continuous intensity |
| Polarizing kit | Polarizer and the analyzer can be removed from the optical path, the analyzer can be rotated 360 °. |
| Photo
accessories |
Photo tube（with PK mount）,photo eyepiece 3.2X |
| Video
accessories |
CTV0.35X/CTV0.5X/CTV0.65X/1.0X |
| software | specialized metallographic analysis software |
