ZMPJ-1-350 automatic grinding machine

ZMPJ-1-350 automatic grinding machine

• the whole machine adopts high-definition LCD touch screen for control and display, which is easy to operate, clear and intuitive
• center pressure and single point pressure are two operation modes, and the most appropriate mode can be selected according to the working conditions
• the sample chuck can be loaded, unloaded and converted quickly, and the chuck with different diameters can be used flexibly
• automatic grinding system, with fixed time and speed, and automatic opening and closing function of water system, effectively replacing manual operation
• automatic locking function of grinding head electromagnetic lock, safe and convenient
• DC brushless motor, long service life, ultra quiet experience
• it can store more than ten programs and set different parameters for different samples
• equipped with diamond grinding needle, which can flatten the surface of the grinding wheel and improve the utilization rate of the grinding wheel
• the half rotation design of the sample clamping plate, combined with the inner lighting system, is convenient for taking and placing samples

ZMPJ-1-350 automatic grinding machine is a grinding equipment controlled by single chip microcomputer. Its body is made of ABS material. It has novel and beautiful appearance, corrosion resistance and durability. The grinding wheel disc can be stepless adjusted to support forward and reverse rotation. Grinding head pressurization supports two modes: central pressure and single point pneumatic. Imported pressure regulating valve is adopted to ensure stable pressure. High Definition LCD touch screen is used for control and display, which is easy to operate, clear and intuitive. The motor is a DC brushless motor, which does not need to replace the brush. It has long service life, ultra quiet operation, and strong motor power to bring efficient grinding experience. Precision cast iron supporting chassis design ensures precise rotary balance; The leakage proof design of the main shaft effectively protects the bearings. The automatic grinding system of this machine can effectively replace the manual grinding process. The number of sample holders can reach 6, which greatly saves labor, improves the grinding quality and sample preparation efficiency. It is an ideal choice for the new type of automatic metallographic sample preparation equipment.

Grinding wheel specification:350mm, 80\or 120#

Disc speed:Stepless speed regulation 100~1000r/min

Disc steering:Both clockwise and counterclockwise, switchable

Disc motor:DC brushless motor, 220V, 1.2kW

Grinding head motor:Stepping motor, 200W

Grinding head speed:Stepless speed regulation 20~120r/min

Timing adjustable time:0~99min

Sample holding quantity:6

Sample clamping specification:Φ 25mm, Φ 30mm, Φ 40mm any specification

(special specifications can be customized)

Pressurization mode:Single point pneumatic pressurization and central pneumatic pressurization

Single point pressurization pressure:0~50N

Center pressurization pressure:0~160N

Display and operation:7-inch high-definition LCD touch screen, grinding head automatic locking function, automatic water outlet function

Input power supply:Single phase 220V, 50Hz, 8A

Overall dimension:800×800×760mm

Net weight:96kg

Packing:

Main body:1 set

Automatic grinding head: 1

Specimen chuck: 2

Sample horizontal tray: 1

grinding wheel: 350mm 1 piece

Water inlet pipe

Water inlet pipe of washing machine 1 piece

Outlet pipe Φ 32mm1 piece

Inlet filter screen 1

Trachea Φ 6mm 1 piece

Grinding head connecting line 2 pcs
