MIC-2ER-L slit lamp microscope
Large view range, high magnification, good scalability
Three-step drum zoom design, easier to use
Maximum 14mm spot checks greater extent of disease
21.5mm high eye point more comfortable to check
All optical lens are made from import materials, carried out moisture proof, mould proof and coating process, which prove its good optical performance in different weather condition
High quality micro-positioning platform, easy to operate
Reserved digital upgrade interface, you can upgraded to a digital slit lamp
Model | MIC-2ER-L |
Microscope Type | Galileo Parallel |
Magnifications change way | Drum Three Magnifications |
Eyepiece Magnification | 12.5x |
Total Magnifications | 10X 16X 25X |
Diopter Adjustment | -5D ~ +5D |
Illumination | Three Steps (Stepless Optional) |
Slit Width | 0-14mm Continuous |
Slit Height | 1-14mm Continuous |
Slit Angle | 0°-180° Adjustable |
Slit Inclination Angle | 5° 10° 15° 20° |
Light Spot Diameter | 0.2mm,1mm,2mm,5mm,10mm,14mm |
Filter | Heat Absorption;Grey;Redfree;Cobalt Blue |
Fixation | Red LED |
Electrical | |
Illumination Bulb | German Osram Halogen Tungsten Lamp Led Lamp (Optional) |
Input Voltage | 110V/220V(±10%) |
Input Power | 60VA |
Diffuse Lens | Yes |
Preset Lens | Yes |
Laser Interface | Optional |
Applanation Tonometer Interface | Yes |
Base Movement | X: 100mm ± 3 Y: 75mm ± 3 Z: 30mm ± 3 |
